Image is representational - see manufacturer specifications
TE Connectivity / CII Brand Authorized Distributor

JMGAPD-26L

The JMGAPD-26L is an electromechanical relay with a contact rating of up to 1 amp for high-reliability applications. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The JMGAPD-26L is a hermetically sealed relay designed for switching electrical circuits. It operates with a nominal coil voltage of 26.5 VDC and has a coil resistance of 1560 ohms. This relay is capable of switching resistive loads from low level up to 1 amp at 28 VDC for 100,000 operations. Built for harsh environments, it features a wide operating temperature range from -65°C to +125°C and can withstand significant vibration and shock. Its fast switching times, with a maximum operate time of 2.0 ms and release time of 4.0 ms, make it suitable for demanding control systems.

Search Keywords: JMGAPD26L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / CII Brand
Part No:
JMGAPD-26L
Alias/AKA:
M39016/18-030L, 1617148-3
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536410050
COO:
IN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Type:
Military Relay
Relay Construction:
Non-Latching
Contact Arrangement:
DPDT
AC Coil Voltage:
N/A
DC Coil Voltage:
26.5 V
Maximum Current Rating:
1 A
Coil Current:
16.99 mA
Coil Resistance:
1.56 KOhm
Mounting:
Through Hole
Operating Temperature:
-65 to 125 °C
Termination Style:
PC Pin

IN STOCK: 0

MOQ for out of Stock Qty: 13

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
13
$186.35
25
$102.60
38
$71.25
50 +
$69.82
