PE0SXSS60 by te connectivity / corcom brand
Image is representational - see manufacturer specifications
TE Connectivity / Corcom Brand Authorized Distributor

PE0SXSS60

Power Entry Module EMI/RFI Filtered M 3 POS 250VAC 6A Switch/Fuse/Voltage Selector RA 1 Port ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

PE0SXSS60 is a selectable fuseholder designed for power distribution applications with medical-grade filtering and dual voltage selection capability. The device operates at rated voltages of 120/250 VAC with operating voltages of 115/230 VAC at 50/60 Hz, and accepts 1 or 2 fuses in 1/4" x 1-1/4" or 5 x 20mm formats with a rated current of 10A. It features a medical filter (S model) with maximum leakage current of 0.25 mA at 120 VAC 60Hz and 0.50 mA at 250 VAC 50Hz, providing line-to-ground isolation of 1500 VAC and line-to-line isolation of 1450 VDC. The fuseholder operates reliably across an ambient temperature range of -10°C to +40°C with storage capability from -40°C to +85°C, making it suitable for medical equipment, industrial power distribution, and safety-critical applications requiring filtered power protection.

Search Keywords: PE0SXSS60

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Corcom Brand
Part No:
PE0SXSS60
Alias/AKA:
4-6609929-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8537109170
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
48
Package Type:
BOX
Type:
EMI/RFI Filtered
Body Orientation:
Right Angle
Gender:
M
Mounting:
Flange Mount
Termination Method:
Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
6 A
Operating Frequency:
30 to 30000 KHz
Operating Temperature:
N/A

IN STOCK: 24

Ships today, if you order in

MOQ for out of Stock Qty: 12

Factory Lead-Time 31 Weeks

Price (USD)

Qty
Unit Price
1
$42.76
5
$42.64
12
$42.54
24
$31.91
36
$29.78
48 +
$29.18
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models
