2366509-1 by te connectivity / deutsch automotive
Image is representational - see mfr. specs

2366509-1

TE Connectivity / Deutsch Automotive

48POS,HYBRID,PIN HSG ASSY,SLD,COD A

RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

48POS,HYBRID,PIN HSG ASSY,SLD,COD A

Search Keywords: 23665091

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
2366509-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mating Alignment Type:
Keyed
Nominal Voltage Architecture:
24 V
Number of Positions:
48
Primary Product Color:
Black
Connector & Housing Type:
Receptacle
Connector System:
Cable-to-Cable
Circuit Application:
Power & Signal
Contact Size:
Size 16 , Size 20
Primary Locking Feature:
Locking Lance
Operating Temperature Range:
-40 – 125 °C, -40 – 257 °F
Connector Position Assurance Capable:
Yes
Connector Shape:
Rectangular
Connector & Contact Terminates To:
Wire & Cable
Connector Mounting Type:
Cable Mount (Free-Hanging)
Number of Rows:
6
Operating Temperature (Max):
125 °C, 257 °F
Contact Current Rating (Max):
13 A
Sealable:
Yes
Mating Alignment:
With

IN STOCK: 145

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$11.37
25
$6.60
50
$6.51
100
$6.38
250
$6.34
500
$6.31
1,000 +
$6.27
Log in for special pricing Click for Quote Price Match Request
