DRC12-70PC by te connectivity / deutsch automotive
Image is representational - see mfr. specs

DRC12-70PC

TE Connectivity / Deutsch Automotive

REC, 70P, BLK, N, FLANGE, C ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / Deutsch Automotive part DRC12-70PC is a reliable and high-quality electrical connector. It features a rectangular configuration with 70 pins, ensuring secure and efficient transmission of signals in automotive applications. The connector comes in a sleek black color, enhancing its professional appearance. The N designation signifies a standard gender configuration (neither male nor female). Additionally, this connector includes a durable flange for easy installation and stability. Designed to meet rigorous automotive industry standards, the TE Connectivity / Deutsch Automotive DRC12-70PC is a top choice for ensuring reliable and efficient electrical connections in automotive systems.

Search Keywords: DRC1270PC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DRC12-70PC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Product Width:
4.993 in, 126.82 mm
Cable Exit Angle:
180°
Centerline (Pitch):
.216 in, 5.49 mm
Packaging Quantity:
21
Serviceable:
Yes
Primary Product Color:
Black
UL Flammability Rating:
20mm Flame Test per Standard UL-94
Number of Rows:
5
Blank Cavity Position:
0
Strain Relief:
Add By Accessory
Packaging Method:
Box
Terminal Position Assurance:
No
Primary Locking Feature:
Contact Retainer
Connector System:
Wire-to-Wire
Contact Current Rating (Max):
13 A
Number of Positions:
70
Degree of Protection:
IP68 , IP6K9K
Operating Temperature (Max):
125 °C, 257 °F
Connector & Contact Terminates To:
Wire & Cable
Connector & Housing Type:
Housing for Male Terminals
Operating Voltage:
250 VAC, 250 VDC
Circuit Application:
Power & Signal
Row-to-Row Spacing:
.216 in, 5.49 mm
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Product Length:
1.757 in, 44.63 mm
Mating Pin Diameter:
.063 in, 1.59 mm
Agency/Standard:
SAE J2030
Sealable:
Yes
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Connector Position Assurance Capable:
No
Mating Alignment:
With
Mating Alignment Type:
Keyed
Housing Material:
PPS GF
Connector Mounting Type:
Panel Mount
Connector Height:
2.32 in, 58.93 mm
Connector Shape:
Rectangular
Contact Type:
Pin
Contact Size:
Size 16

IN STOCK: 12

Can Ship immediately

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
1
$43.38
5
$42.95
10
$36.97
25
$36.60
50
$35.93
100
$34.66
250 +
$32.54
