DRC16-40S by te connectivity / deutsch automotive
Image is representational - see mfr. specs

DRC16-40S

TE Connectivity / Deutsch Automotive

The DRC16-40S is a rectangular, 40-cavity plug connector that accepts size 16 DEUTSCH socket contacts. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DRC16-40S is a rectangular plug connector from the DEUTSCH DRC series, designed to house 40 size 16 socket contacts. It features a rugged thermoplastic shell and utilizes a jackscrew for secure mating. This connector is rated for 13 amps per contact and accepts wire gauges from 14-20 AWG. It is environmentally sealed to an IP68 rating and operates across a temperature range of -55°C to +125°C, ensuring durability through 100 mating cycles and resistance to high vibration. Its robust design makes it suitable for in-line connections in industrial and commercial transportation applications where reliable performance is critical.

Search Keywords: DRC1640S

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DRC16-40S
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Rectangular3726
Mounting:
Panel Mount3718
Body Orientation:
Straight3707
Gender:
PL3712
Pitch:
N/A
Termination Method:
N/A
Number of Contacts:
40
Maximum Voltage Rating:
2503716VDC
Maximum Current Rating:
13/Contact A
Operating Temperature:
-55 to 125 °C

IN STOCK: 258

Can Ship immediately

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
1
$28.98
5
$21.42
25
$20.82
50
$20.61
100
$20.45
250
$20.34
500 +
$20.25
