DRC18-40SAE by te connectivity / deutsch automotive
Image is representational - see manufacturer specifications

DRC18-40SAE

TE Connectivity / Deutsch Automotive

PLG, 40P, BLK, E, A ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE CONNECTIVITY / DEUTSCH AUTOMOTIVE DRC18-40SAE is a high-performance, 40-pin plug connector designed for automotive applications. Engineered for durability and reliability, this connector is part of the trusted DEUTSCH DT Series, known for its superior environmental sealing, robust construction, and easy-to-use interface. Featuring a sleek black housing, and keyed with an 'E' arrangement, it ensures secure and correct connections every time. The DRC18-40SAE is perfect for demanding environments, offering exceptional protection against moisture, dirt, and vibrations. Ideal for integrating with diverse vehicular systems, this plug connector combines ease of use with rugged performance, making it an excellent choice for OEMs and aftermarket applications.

Search Keywords: DRC1840SAE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DRC18-40SAE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Primary Locking Feature:
Contact Retainer
Terminal Position Assurance:
No
Agency/Standard:
SAE J2030
Number of Positions:
40
UL Flammability Rating:
20mm Flame Test per Standard UL-94
Packaging Quantity:
125
Connector System:
Wire-to-Wire
Number of Rows:
4
Packaging Method:
Box
Strain Relief:
Add By Accessory
Serviceable:
Yes
Sealable:
Yes
Connector Position Assurance Capable:
No
Connector & Housing Type:
Housing for female terminals
Blank Cavity Position:
0
Connector Mounting Type:
Cable Mount (Free-Hanging)
Primary Product Color:
Black
Contact Current Rating (Max):
13 A
Cable Exit Angle:
180°
Operating Temperature (Max):
125 °C, 257 °F
Row-to-Row Spacing:
.216 in, 5.49 mm
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Product Width:
2.868 in, 72.85 mm
Product Length:
1.592 in, 40.44 mm
Centerline (Pitch):
.216 in, 5.49 mm
Degree of Protection:
IP68 , IP6K9K
Mating Pin Diameter:
.063 in, 1.59 mm
Operating Voltage:
250 VAC, 250 VDC
Circuit Application:
Power & Signal
Connector & Contact Terminates To:
Wire & Cable
Contact Type:
Socket
Connector Shape:
Rectangular
Contact Size:
Size 16
Mating Alignment:
With
Housing Material:
PPS GF
Mating Alignment Type:
Keyed
Connector Height:
1.202 in, 30.53 mm

IN STOCK: 22

Ships today, if you order in

On Order: 125   can ship 10/12/26

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
1
$32.96
5
$31.87
10
$26.83
25
$24.98
50
$23.67
100
$22.53
250 +
$21.13
