DT04-12PA-P075 by te connectivity / deutsch automotive
Image is representational - see manufacturer specifications
TE Connectivity / Deutsch Automotive Authorized Distributor

DT04-12PA-P075

REC, 12P, GRY, BUSBAR 3X4, NICKEL, A ...

View Datasheet Ask the Datasheet
RoHS Compliant
Pack Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE Connectivity / Deutsch Automotive part DT04-12PA-P075 is a reliable and efficient connector designed for automotive applications. It features a 12-pin configuration and a gray color, making it easy to identify and connect properly. The connector uses a busbar 3x4 design, providing excellent conductivity and minimizing the risk of electrical failures. The nickel-plated construction ensures durability and corrosion resistance, making it suitable for use in various environments and conditions. With its REC (Rectangular) design, this connector offers a secure and reliable electrical connection.

Search Keywords: DT0412PAP075

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DT04-12PA-P075
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536698000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
Pack
Circuit Application:
Power & Signal
Connector Code:
A
Degree of Protection:
IP68 , IP6K9K
Primary Locking Feature:
Integrated in Housing
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Packaging Method:
Box
Number of Positions:
12
Strain Relief:
Add By Accessory
Terminal Position Assurance:
Yes
Centerline (Pitch):
.359 in, 9.12 mm
Connector & Contact Terminates To:
Bus Bar , Wire & Cable
Length:
2.043 in, 51.89 mm
Hybrid Connector:
No
Connector Mounting Type:
Cable Mount (Free-Hanging) , Fixing Screw
UL Flammability Rating:
12mm Flame Test per Standard UL-94
Height:
.876 in, 22.25 mm
Agency/Standard:
SAE J2030
Mounting Feature:
With
Connector Position Assurance Capable:
No
Mating Pin Diameter:
.0625 in, 1.59 mm
Cable Exit Angle:
180 °
Operating Temperature (Max):
125 °C, 257 °F
Connector & Housing Type:
Housing for Male Terminals
Packaging Quantity:
250
Polarized:
Yes
Row-to-Row Spacing:
.175 in, 4.45 mm
Primary Product Color:
Gray
Connector System:
Bus Bar-to-Wire
Serviceable:
Yes
Sealable:
Yes
Width:
1.597 in, 40.56 mm
Contact Current Rating (Max):
13 A
Number of Rows:
2
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Operating Voltage:
250 VAC
Body Material:
PA GF
Blank Cavity Position:
0

IN STOCK: 431

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
5
$11.54
25
$10.67
50
$10.48
100
$10.00
250
$9.69
500
$8.89
1,000 +
$8.87
