DT04-2P-CE04

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

DT04-2P-CE04

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

US

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1

Operating Temperature Range:

-55 – 125 °C, -67 – 257 °F

Connector Mounting Type:

Cable Mount (Free-Hanging) , Fixing Screw

Agency/Standard:

SAE J2030

Operating Temperature (Max):

125 °C, 257 °F

Connector & Housing Type:

Housing for Male Terminals

Packaging Quantity:

800

Height:

.67 in, 17.02 mm

Number of Positions:

2

Length:

2.251 in, 57.18 mm

Operating Voltage:

250 VAC

Blank Cavity Position:

0

Width:

.675 in, 17.15 mm

Hybrid Connector:

No

Degree of Protection:

IP68 , IP6K9K

Number of Rows:

1

Connector System:

Wire-to-Wire

Circuit Application:

Power & Signal

Serviceable:

Yes

Strain Relief:

Add By Accessory

Mating Pin Diameter:

.0625 in, 1.59 mm

Sealable:

Yes

Terminal Position Assurance:

Yes

Cable Exit Angle:

180 °

Polarized:

Yes

UL Flammability Rating:

12mm Flame Test per Standard UL-94

Connector Position Assurance Capable:

No

Nominal Voltage Architecture:

12 V, 24 V, 48 V

Contact Current Rating (Max):

13 A

Centerline (Pitch):

.215 in, 5.46 mm

Mounting Feature:

With

Primary Locking Feature:

Integrated in Housing

Packaging Method:

Box

Body Material:

PA GF

Primary Product Color:

Gray
