Name: DT06-08SA-CE11
Brand: Te Connectivity Deutsch Automotive
SKU: 50873731
Price: 42.24 USD
Availability: InStock

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

DT06-08SA-CE11

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

MX

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

1

Package Type:

Pack

Height:

1.465 in, 37.21 mm

Packaging Method:

Box

Connector System:

Wire-to-Wire

Primary Locking Feature:

Integrated in Housing

Length:

1.267 in, 32.18 mm

Width:

.872 in, 22.15 mm

Degree of Protection:

IP68 , IP6K9K

Body Material:

PA GF

Number of Positions:

8

UL Flammability Rating:

12mm Flame Test per Standard UL-94

Terminal Position Assurance:

Yes

Operating Voltage:

250 VAC

Agency/Standard:

SAE J2030

Number of Rows:

2

Hybrid Connector:

No

Strain Relief:

Add By Accessory

Operating Temperature Range:

-55 – 125 °C, -67 – 257 °F

Centerline (Pitch):

.359 in, 9.12 mm

Serviceable:

Yes

Operating Temperature (Max):

125 °C, 257 °F

Packaging Quantity:

500

Primary Product Color:

Black

Circuit Application:

Power & Signal

Contact Current Rating (Max):

13 A

Nominal Voltage Architecture:

12 V, 24 V, 48 V

Sealable:

Yes

Mounting Feature:

Without

Polarized:

Yes

Cable Exit Angle:

180 °

Row-to-Row Spacing:

.175 in, 4.45 mm

Connector Position Assurance Capable:

No

Mating Pin Diameter:

.0625 in, 1.59 mm

Connector & Housing Type:

Housing for female terminals

Blank Cavity Position:

0

Connector Code:

A
