DT06-12SB-EP06

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

DT06-12SB-EP06

RoHS:

Yes

HTS:

8538906000

COO:

US

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1

Circuit Application:

Power & Signal

Blank Cavity Position:

0

Degree of Protection:

IP68 , IP6K9K

Packaging Method:

Box

Operating Voltage:

250 VAC

Primary Locking Feature:

Integrated in Housing

Nominal Voltage Architecture:

12 V, 24 V, 48 V

Height:

1.597 in, 40.56 mm

Connector System:

Wire-to-Wire

Contact Current Rating (Max):

13 A

Hybrid Connector:

No

Mounting Feature:

Without

Terminal Position Assurance:

Yes

Packaging Quantity:

450

Cable Exit Angle:

180 °

Body Material:

PA GF

UL Flammability Rating:

12mm Flame Test per Standard UL-94

Mating Pin Diameter:

.0625 in, 1.59 mm

Operating Temperature (Max):

125 °C, 257 °F

Primary Product Color:

Black

Number of Rows:

2

Centerline (Pitch):

.359 in, 9.12 mm

Polarized:

Yes

Agency/Standard:

SAE J2030

Number of Positions:

12

Strain Relief:

Add By Accessory

Connector Code:

B

Connector Position Assurance Capable:

No

Row-to-Row Spacing:

.175 in, 4.45 mm

Serviceable:

Yes

Operating Temperature Range:

-55 – 125 °C, -67 – 257 °F

Width:

.82 in, 20.83 mm

Connector & Housing Type:

Housing for female terminals

Sealable:

Yes

Length:

1.268 in, 32.21 mm
