DT06-2S-C017

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

DT06-2S-C017

RoHS:

Yes

HTS:

8538906000

COO:

MX

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1

Cable Exit Angle:

180 °

Blank Cavity Position:

2

UL Flammability Rating:

12mm Flame Test per Standard UL-94

Sealable:

Yes

Hybrid Connector:

No

Length:

1.278 in, 32.46 mm

Connector & Housing Type:

Housing for female terminals

Agency/Standard:

SAE J2030

Operating Temperature Range:

-55 – 125 °C, -67 – 257 °F

Operating Temperature (Max):

125 °C, 257 °F

Operating Voltage:

250 VAC

Height:

.621 in, 15.77 mm

Mating Pin Diameter:

.0625 in, 1.59 mm

Strain Relief:

Add By Accessory

Packaging Method:

Box

Serviceable:

Yes

Width:

.591 in, 15.01 mm

Primary Product Color:

Gray

Polarized:

Yes

Number of Rows:

1

Circuit Application:

Power & Signal

Connector Position Assurance Capable:

No

Primary Locking Feature:

Integrated in Housing

Terminal Position Assurance:

Yes

Packaging Quantity:

1600

Centerline (Pitch):

.215 in, 5.46 mm

Body Material:

PA GF

Mounting Feature:

Without

Connector System:

Wire-to-Wire

Number of Positions:

2

Degree of Protection:

IP68 , IP6K9K

Nominal Voltage Architecture:

12 V, 24 V, 48 V

Contact Current Rating (Max):

13 A
