Name: DT06-4S-C017
Brand: Te Connectivity Deutsch Automotive
SKU: 50873799
Price: 29.5 USD
Availability: BackOrder

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

DT06-4S-C017

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

MX

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

1

Package Type:

Pack

Operating Voltage:

250 VAC

Mating Pin Diameter:

.0625 in, 1.59 mm

Sealable:

Yes

Agency/Standard:

SAE J2030

Primary Product Color:

Gray

Mounting Feature:

Without

Operating Temperature (Max):

125 °C, 257 °F

Circuit Application:

Power & Signal

Contact Current Rating (Max):

13 A

Operating Temperature Range:

-55 – 125 °C, -67 – 257 °F

Primary Locking Feature:

Integrated in Housing

Row-to-Row Spacing:

.359 in, 9.12 mm

Terminal Position Assurance:

Yes

UL Flammability Rating:

12mm Flame Test per Standard UL-94

Body Material:

PA GF

Blank Cavity Position:

4

Nominal Voltage Architecture:

12 V, 24 V, 48 V

Connector System:

Wire-to-Wire

Polarized:

Yes

Packaging Method:

Box

Cable Exit Angle:

180 °

Serviceable:

Yes

Connector Position Assurance Capable:

No

Width:

.82 in, 20.83 mm

Packaging Quantity:

900

Number of Rows:

2

Strain Relief:

Add By Accessory

Connector & Housing Type:

Housing for female terminals

Height:

.771 in, 19.58 mm

Hybrid Connector:

No

Length:

1.328 in, 33.73 mm

Centerline (Pitch):

.175 in, 4.45 mm

Degree of Protection:

IP68 , IP6K9K

Number of Positions:

4
