DTM04-6P-E005 by te connectivity / deutsch automotive

Image is representational - see mfr. specs

DTM04-6P-E005

Name: DTM04-6P-E005
Brand: Te Connectivity Deutsch Automotive
SKU: 50874937
Price: 29.75 USD
Availability: InStock

TE Connectivity / Deutsch Automotive

REC, 6P, BLK, N, CAP ...

Datasheet

RoHS Compliant

Pack Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The DTM04-6P-E005 is a 6-position receptacle connector from the DTM series (EE04 modification) designed for industrial and commercial transportation applications. This sealed connector features a welded flange with end cap and shrink boot adapter in black, providing environmental protection for harsh operating conditions. The receptacle accommodates size 20 contacts and is compatible with wire sizes 14–22 AWG (2.5–0.35 mm²) with a standard sealing range of 0.053–0.120 inches (1.35–3.05 mm) outside diameter. The connector has overall dimensions of 1.185 inches (30.10 mm) length, 0.817 inches (20.75 mm) height, and 0.600 inches (15.24 mm) width. It is commonly used in serial data communications systems, including SAE J1939 CAN bus networks, and requires a secondary wedgelock (sold separately) for secure mating and keying.

Product Highlights:

Potential Applications:

Search Keywords: DTM046PE005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

DTM04-6P-E005

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
