HD10-9-96P-BE09 by te connectivity / deutsch automotive

Image is representational - see mfr. specs

HD10-9-96P-BE09

Name: HD10-9-96P-BE09
Brand: Te Connectivity Deutsch Automotive
SKU: 50875974
Price: 47.45 USD
Availability: InStock

TE Connectivity / Deutsch Automotive

Circular Connector, 9 Contact(s), Male ...

Datasheet

RoHS Compliant

Pack Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The HD10-9-96P-BE09 is a square flange receptacle connector designed for industrial and commercial transportation systems, featuring 9 size-16 cavities with threaded rear mounting. The connector is constructed with a glass-filled polyamide housing and molded-in copper alloy contacts with nickel plating. It operates across a temperature range of -40°C to +125°C for gold-plated contacts and -40°C to +105°C for tin-plated contacts, with a maximum voltage rating of 250 volts AC and current capacity up to 17 amps (gold) or 8 amps (tin). The connector maintains an insulation resistance of 100 megohms minimum and withstands physical shock of 50 g half-sine pulses (11 ms duration) and random vibration of 10 g for 8 hours per plane. This connector is commonly used in on-highway and off-highway vehicle systems, diagnostic interfaces, and power distribution applications where environmental sealing and reliable mating are critical.

Product Highlights:

Potential Applications:

Search Keywords: HD10996PBE09

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

HD10-9-96P-BE09

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
