HD36-24-21SN-072

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

HD36-24-21SN-072

RoHS:

Yes

HTS:

8538908180

COO:

MX

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1

Terminal Position Assurance:

No

Connector System:

Wire-to-Wire

Degree of Protection:

IP67

Strain Relief:

Add By Accessory

Serviceable:

Yes

Connector Position Assurance Capable:

No

Number of Positions:

21

Connector & Housing Type:

Housing for female terminals

Sealable:

Yes

Cable Exit Angle:

180°

Blank Cavity Position:

0

Primary Locking Feature:

Contact Retainer

Packaging Quantity:

80

Packaging Method:

Box

Contact Current Rating (Max):

13 A, 25 A

Mating Pin Diameter:

.063 in, .094 in, 1.59 mm, 2.39 mm

Nominal Voltage Architecture:

12 V, 24 V

Product Length:

2.57 in, 65.28 mm

Product Width:

1.942 in, 49.32 mm

Operating Voltage:

250 VAC, 250 VDC

Operating Temperature Range:

-55 – 125 °C, -67 – 257 °F

Operating Temperature (Max):

125 °C, 257 °F

Connector & Contact Terminates To:

Wire & Cable

Circuit Application:

Power & Signal

Housing Material:

Aluminum

Contact Type:

Socket

Connector Mounting Type:

Cable Mount (Free-Hanging)

Mating Alignment:

With

Mating Alignment Type:

Guide Slot

Connector Shape:

Circular

Contact Size:

Size 12 , Size 16

Connector Height:

1.942 in, 49.32 mm
