HDP24-24-23PT

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

HDP24-24-23PT

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

US

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

30

Package Type:

Tray

UL Flammability Rating:

20mm Flame Test per Standard UL-94

Number of Positions:

23

Strain Relief:

Add By Accessory

Degree of Protection:

IP67

Connector Position Assurance Capable:

No

Connector System:

Wire-to-Wire

Serviceable:

Yes

Sealable:

Yes

Connector & Housing Type:

Housing for Male Terminals

Terminal Position Assurance:

No

Blank Cavity Position:

0

Primary Product Color:

Black

Cable Exit Angle:

180°

Contact Current Rating (Max):

13 A

Packaging Method:

Box

Primary Locking Feature:

Contact Retainer

Nominal Voltage Architecture:

12 V, 24 V, 48 V

Operating Voltage:

250 VAC, 250 VDC

Mating Pin Diameter:

.063 in, 1.59 mm

Operating Temperature (Max):

125 °C, 257 °F

Operating Temperature Range:

-55 – 125 °C, -67 – 257 °F

Product Length:

1.648 in, 41.86 mm

Product Width:

2 in, 50.8 mm

Connector & Contact Terminates To:

Wire & Cable

Circuit Application:

Power & Signal

Connector Shape:

Circular

Connector Mounting Type:

Panel Mount

Mating Alignment Type:

Guide Post

Connector Height:

1.875 in, 47.63 mm

Mating Alignment:

With

Contact Type:

Housing Material:

PA GF

Contact Size:

Size 16
