154767
TE Connectivity / ERNISMCB 80 M AB VV 7-03 CL * 0007 137 E004 ...
DESCRIPTION
154767 is an 80-pin right-angle male SMC connector designed for high-performance board-to-board and cable interconnection applications. The connector features SMT (surface mount technology) termination with dual-row contact arrangement on a 1.27 mm grid pitch, supporting data rates up to 3 Gbit/s with differential signal transmission capability. Key technical characteristics include a compact form factor with dimensions of 53.95 mm (A), 55.88 mm (B), and 53.55 mm (C), location pegs for precise board placement, and a black insulation body for reliable visual recognition during assembly. The connector employs double-sided spring contacts for superior contact reliability and virtually continuous impedance profile, enabling secure high-speed data transmission. This connector is ideal for modern electronic systems requiring compact, secure, and reliable interconnections with high signal integrity and current-carrying capacity in space-constrained applications.
Search Keywords: 154767
SPECIFICATIONS
IN STOCK: 82
Ships today, if you order in
MOQ for In Stock Qty: 15
MOQ for out of Stock Qty: 15
Factory Lead-Time 24 Weeks
Datasheet
