244836-E by te connectivity / erni

244836-E

TE Connectivity / ERNI

SMCQ 12 M AB VV 8-13 CL * H007 137 E005 ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity/ERNI part 244836-E is a high-quality, reliable and versatile connector. It features a 2-row, 12-pin design with a compact footprint, making it perfect for a variety of applications. This connector is made from durable materials to ensure long-lasting performance and has a reliable contact system for secure connectivity. With its easy-to-use design and excellent electrical properties, TE Connectivity/ERNI part 244836-E is an ideal choice for industrial, automotive and consumer electronic applications.

Search Keywords: 244836E

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / ERNI
Part No:
244836-E
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
280
Package Type:
Reel
PCB Contact Termination Area Plating Material:
Tin
Number of Rows:
2
Contact Current Rating (Max):
1.6 A
Shielded:
No
Connector System:
Board-to-Board
Number of Loaded Positions:
12
Connector Mounting Type:
Board Mount
Number of Positions:
12
PCB Mount Retention:
With
Centerline (Pitch):
.05 in, 1.27 mm
Stackable:
Yes
Operating Temperature (Max):
125 °C, 257 °F
Stack Height:
.069 in, 1.75 mm
Housing Material:
LCP
PCB Mount Orientation:
Vertical
Stacking Configuration:
Stack Through
Approved Standards:
UL
PCB Connector Assembly Type:
PCB Mount Header
Contact Mating Area Plating Material:
Gold (Au)
Agency/Standard:
DIN , UL
Connector Profile:
Low
Packaging Quantity:
280
Sealable:
No
Contact Shape & Form:
Rectangular
PCB Mount Alignment:
With
Connector Contact Load Condition:
Fully Loaded
Connector & Contact Terminates To:
Printed Circuit Board
PCB Contact Termination Area Plating Material Thickness:
157.48 – 236.22 µin, 4 – 6 µm
Connector Height:
.266 in, 6.75 mm
Header Type:
Fully Shrouded
Mating Entry Location:
Top
Connector Width:
.275 in, 7 mm
Industry Standard:
IEC
Number of Columns:
6
Board-to-Board Configuration:
Parallel
Primary Product Color:
Black
Packaging Reel Diameter:
12.99 in, 330 mm
Contact Layout:
Matrix
Mating Alignment:
With
Contact Type:
Pin
Dielectric Withstanding Voltage (Max):
500 Vrms
PCB Mount Alignment Type:
Locating Posts
Profile Height from PCB:
.266 in, 6.75 mm
Mating Alignment Type:
Polarization
Termination Method to Printed Circuit Board:
Surface Mount
Packaging Type:
Tape & Reel
Connector Length:
.5 in, 12.7 mm
Circuit Application:
Power & Signal
UL Flammability Rating:
UL 94V-0
Contact Base Material:
Copper Alloy
Contact Mating Area Length:
.157 in, 4 mm
Row-to-Row Spacing:
.05 in, 1.27 mm
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
PCB Mount Retention Type:
Location Peg

IN STOCK: 1,506

Ships today, if you order in

Minimum Order: 280

Multiple: 280

Factory Lead-Time 13 Weeks
