IM06TS by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

IM06TS

Signal Relay 12VDC 2A DPDT(10x6x5.65)mm THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

TE Connectivity/P&B Brand part IM06TS is a signal relay that operates at 12VDC and can handle a current of up to 2A. It features a double-pole double-throw (DPDT) configuration, making it suitable for various switching applications. The relay has compact dimensions, measuring 10mm x 6mm x 5.65mm, and is designed for through-hole mounting. With its reliable performance and small footprint, the IM06TS is an ideal choice for electronic projects demanding efficient signal relay switching.

Product Highlights:

  • IM Relay Series
  • DC Actuating System
  • Input Voltage = 12 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 2 Amps.

Search Keywords: IM06TS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
IM06TS
Alias/AKA:
2-1462037-7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410030
COO:
PT
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1000
Package Type:
TUBE
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Dimension:
10 x 6 x 5.7 mm
Termination Style:
PC Pin
Coil Current:
11.67 mA
Contact Form:
2 Form C
  Possible Replacement options available.  See Alternatives

IN STOCK: 5,296

Can Ship immediately

On Order: 5,000   can ship 9/27/27
On Order: 5,000   can ship 9/29/27

Minimum Order Quantity: 10

Factory Lead-Time 50 Weeks

Price (USD)

Qty
Unit Price
10
$4.32
50
$3.15
100
$3.01
250
$2.88
500
$2.80
1,000
$2.71
3,000
$2.70
5,000 +
$2.69
