IM07DGR by te connectivity / p-b brand

IM07DGR

TE Connectivity / P&B Brand

Signal Relay 24VDC 5A DPDT(10x7.5x5.65)mm SMD Automotive ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / P&B Brand part IM07DGR is a high-quality signal relay designed for automotive applications. With a compact and space-saving design measuring just 10x7.5x5.65mm, this relay is perfect for applications where space is limited. It operates on a 24VDC voltage and can handle a current of up to 5A. This double-pole, double-throw (DPDT) relay ensures reliable and efficient performance in automotive systems. Its surface-mount device (SMD) installation method makes it easier to integrate into electronic circuits. The IM07DGR relay is a trusted choice for automotive industries, providing excellent electrical switching capabilities while meeting the demanding specifications required for automotive applications.

Search Keywords: IM07DGR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
IM07DGR
RoHS:
Yes
HTS:
8536410050
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Reel
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Termination Style:
Gull Wing
Coil Current:
8.33 mA
Contact Form:
2 Form C

IN STOCK: 992

Ships today, if you order in

On Order: 3,000   can ship 4/22/26

Minimum Order: 100

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
100
$2.400
250
$2.359
500
$2.348
1,000
$2.338
3,000
$2.328
5,000
$2.318
8,000
$2.307
10,000 +
$2.287
Suppliers Standard Package
Log in for special pricing
Click for Quote
