KRPA-11AG-120 by te connectivity / p-b brand

KRPA-11AG-120

TE Connectivity / P&B Brand

Electromechanical Relay 120VAC 2.25KOhm 10A DPDT(35.71x35.71x50.8)mm Socket General Purpose Relay ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part KRPA-11AG-120 is a versatile and reliable electromechanical relay designed for general purpose applications. It operates on 120VAC and features a double-pole, double-throw configuration, allowing it to be used in various switching and control tasks. With a compact size of 35.71x35.71x50.8mm, this relay can easily fit into tight spaces. It offers a coil resistance of 2.25KOhm and is capable of handling up to 10A of current. This relay is compatible with a socket for easy installation and maintenance. Trust TE Connectivity / P&B Brand's KRPA-11AG-120 to deliver exceptional performance and durability in a wide range of applications.

Product Highlights:

  • KRPA Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 120 VAC

Search Keywords: KRPA11AG120

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KRPA-11AG-120
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tray
Relay Construction:
Non-Latching
AC Coil Voltage:
120 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
10 A
Mounting:
Socket
Termination Style:
8-Pin Circular Plug
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 55 °C
Coil Resistance:
2.25 KOhm

IN STOCK: 411

Can Ship immediately

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
1
$49.906
5
$37.150
25
$34.469
50
$34.133
100
$33.613
250
$33.428
500 +
$33.260
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

27E891

Relay Socket - Octal Base - 8-pin - Screw Terminals - Panel or DIN Rail Mount

27E892

Relay Socket - Octal Base - 11-pin - Screw Terminals - Panel or DIN Rail Mount

27E122

Relay Socket - Octal Base - 8P - Screw Tmnls - Panel or TE/P&B Track (NOT DIN Rail) Mount

27E123

Relay Socket - Octal Base - 11P - Screw Tmnls - Panel or TE/P&B Track (NOT DIN Rail) Mount

Show 2 More
