KRPA-5DG-12 by te connectivity / p-b brand

KRPA-5DG-12

TE Connectivity / P&B Brand

Power Relay 12VDC 10A SPDT(35.7x35.7x50.8)mm Socket ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B brand KRPA-5DG-12 is a power relay designed for 12VDC applications. This relay features a single-pole double-throw (SPDT) configuration and has a contact rating of 10A. With dimensions of 35.7 x 35.7 x 50.8mm, this relay is suitable for a variety of industrial and commercial applications. The relay comes with a socket for easy installation and is a reliable solution for controlling electrical circuits.

Product Highlights:

  • KRPA Series
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: KRPA5DG12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KRPA-5DG-12
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT
Maximum Current Rating:
10 A
Mounting:
Socket
Termination Style:
8-Pin Circular Plug
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
120 Ohm

IN STOCK: 0

MOQ for out of Stock Qty: 500

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$32.043
5
$31.106
10
$28.686
25
$27.388
50 +
$26.440
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

27E891

Relay Socket - Octal Base - 8-pin - Screw Terminals - Panel or DIN Rail Mount

27E892

Relay Socket - Octal Base - 11-pin - Screw Terminals - Panel or DIN Rail Mount

27E122

Relay Socket - Octal Base - 8P - Screw Tmnls - Panel or TE/P&B Track (NOT DIN Rail) Mount

27E123

Relay Socket - Octal Base - 11P - Screw Tmnls - Panel or TE/P&B Track (NOT DIN Rail) Mount

Show 2 More
