KUP-14A15-24 by te connectivity / p-b brand

KUP-14A15-24

TE Connectivity / P&B Brand

Power Relay 24VAC 10A 3PDT(39.37x35.7x50)mm Socket ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / P&B Brand part KUP-14A15-24 is a power relay designed for various industrial applications. It is a 3PDT (3 Form C) relay, meaning it has three sets of normally open, normally closed, and common contacts. This relay operates at 24VAC and has a contact rating of 10A, making it suitable for controlling medium-sized electrical loads. With compact dimensions measuring 39.37 x 35.7 x 50 mm, this relay can easily fit in tight spaces. It also comes with a socket for easy mounting and installation. The TE Connectivity / P&B Brand part KUP-14A15-24 is known for its robust construction and reliable performance, making it an excellent choice for applications requiring high switching capabilities and precise control. Whether used in automotive, industrial control, or HVAC systems, this power relay ensures efficient power management and safe operation.

Product Highlights:

  • KUP Series
  • Contact Arrangement = 3 Form C, 3PDT, 3 C/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 24 VAC

Search Keywords: KUP14A1524

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KUP-14A15-24
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
24 V
DC Coil Voltage:
N/A
Contact Arrangement:
3PDT
Maximum Current Rating:
10 A
Mounting:
Socket
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 45 °C
Coil Resistance:
72 Ohm

IN STOCK: 786

Can Ship immediately

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
1
$26.337
10
$18.746
25
$17.469
50
$17.386
100
$17.294
250
$17.211
500 +
$17.119
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
