OJE-SH-112HM,000 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

OJE-SH-112HM,000

3-10 Amp Miniature,PC Board Relay ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The OJE-SH-112HM,000 is a versatile and reliable miniature PC board relay from TE Connectivity / P&B Brand. With a current rating of 3-10 Amps, this compact relay is designed to handle a wide range of applications. It is constructed with high-quality materials to ensure durability and long-lasting performance. This relay is easy to install and features a compact design that saves valuable space on the PCB. Whether used in automotive, industrial, or consumer electronics, the OJE-SH-112HM,000 offers dependable and efficient switching capabilities.

Product Highlights:

  • OJE Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: OJESH112HM000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
OJE-SH-112HM,000
Alias/AKA:
1461402-6
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
OTHER
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
10 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-30 to 60 °C
Coil Resistance:
320 Ohm

IN STOCK: 6,091

Ships today, if you order in

On Order: 5,000   can ship 4/19/27

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
100
$2.01
300
$1.84
500
$1.79
1,000
$1.51
2,500
$1.42
5,000
$1.40
7,500
$1.39
10,000 +
$1.38
