PRD-11DH0-12 by te connectivity / p-b brand

PRD-11DH0-12

TE Connectivity / P&B Brand

Power Relay 12VDC 20A DPDT(85.73x63.8x63.5)mm Chassis Mount ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PRD-11DH0-12 from TE Connectivity / P&B Brand is chassis mount double pole double throw (DPDT) power relay with 12VDC coil voltage and 71 Ohms coil resistance. This relay has 20A contact curent and 125VDC max switching voltage. Dimensions of this relay are: 85.73 mm x 63.8 mm x 63.5 mm. Operating temperature range is from -55°C to 80°C.

Product Highlights:

  • PRD Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 20 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: PRD11DH012

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
PRD-11DH0-12
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Mounting:
N/A
Termination Style:
Screw Terminal
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 80 °C

IN STOCK: 106

Ships today, if you order in

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
1
$98.018
5
$95.125
20
$93.241
40
$87.805
60
$87.361
100
$85.661
260 +
$82.690
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
