RT314005 by te connectivity / p-b brand

RT314005

TE Connectivity / P&B Brand

Power Relay 5VDC 16A SPDT(29mm 12.7mm 15.7mm) THT ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / P&B Brand part RT314005 is a high-quality power relay designed with a 5VDC coil voltage and a compact form factor. This single pole, double throw relay offers a versatile and reliable solution for electrical control applications.With a maximum current rating of 16A, this power relay is capable of handling significant electrical loads. Its Through Hole Technology (THT) ensures a secure and stable connection on a printed circuit board.The dimensions of this relay are 29mm in length, 12.7mm in width, and 15.7mm in height. Its compact size allows for easy integration into various electronic devices and systems.TE Connectivity / P&B Brand part RT314005 is a reliable and efficient power relay suitable for a wide range of applications, including industrial machinery, automation equipment, HVAC systems, and more. Trust this high-performance component for consistent performance and long-lasting durability.

Product Highlights:

  • RT1 Series
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O
  • Contact Current Rating = 16 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: RT314005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RT314005
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
62 Ohm
  Possible Replacement options available.  See Alternatives

IN STOCK: 43,980

Ships today, if you order in

Minimum Order: 20

Multiple: 20

Factory Lead-Time 14 Weeks

Price (CAD)

Qty
Unit Price
20
$4.288
60
$3.583
260
$3.522
500
$3.031
1,000
$3.017
2,500
$2.941
5,000
$2.895
7,500 +
$2.849
Suppliers Standard Package
Log in for special pricing
Click for Quote
