RT314524 by te connectivity / p-b brand
Image is representational - see mfr. specs

RT314524

TE Connectivity / P&B Brand

Power PCB Relay - 1 form C (CO) - 24VAC Coil - 16A Contact Rating - 400VAC Switching - Pinning 5mm - Flux Proof - PC Pin - Through Hole. ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The RT314524 from TE Connectivity / P&B Brand is through hole mounting power PCB relay with 1 form C (CO) contact arrangement, 24VAC coil voltage and 350 Ohms coil resistance. This flux proof relay has 5mm pinning, silver nickel (AgNi) contacts, 16A contact current rating, 400VAC maximum switching voltage and PC pin termination. Operating temperature range is from -40°C to 70°C.

Product Highlights:

  • RT1 Series
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O
  • Contact Current Rating = 16 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 24 VAC

Search Keywords: RT314524

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RT314524
Alias/AKA:
1393240-4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
AT
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
24 V
DC Coil Voltage:
N/A
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 70 °C
Coil Resistance:
350 Ohm

IN STOCK: 1,938

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$5.49
50
$4.46
100
$4.25
250
$4.13
500
$3.90
1,000
$3.80
2,500
$2.97
5,000 +
$2.93
Suppliers Standard Package
