RZ03-1C4-D005 by te connectivity / p-b brand
Image is representational - see mfr. specs

RZ03-1C4-D005

TE Connectivity / P&B Brand

Power Relay 5VDC 16A SPDT(29x12.7x15.7)mm THT ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part RZ03-1C4-D005 is a versatile and high-performance power relay designed to handle various applications. With a compact size of 29x12.7x15.7mm, this relay is easy to accommodate in tight spaces.Operating at a voltage of 5VDC, this relay is capable of switching up to 16A of current. Its single-pole double-throw (SPDT) design enables it to redirect power between two different circuits, providing maximum flexibility in use.Built with Through-Hole Technology (THT), this power relay offers secure and reliable connections. Its durable construction ensures long-lasting performance even in demanding environments.Whether used in industrial machinery, automation systems, or electronic devices, the TE Connectivity / P&B RZ03-1C4-D005 power relay is a trustworthy choice for controlling and distributing power effectively and safely.

Search Keywords: RZ031C4D005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RZ03-1C4-D005
Alias/AKA:
1-1415899-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
AT
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C

IN STOCK: 350

Ships today, if you order in

On Order: 3,000   can ship 7/15/26

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
20
$2.41
100
$2.01
260
$1.92
500
$1.84
1,000
$1.79
2,500
$1.78
5,000
$1.77
7,500 +
$1.76
Suppliers Standard Package
