T77S1D10-05 by te connectivity / p-b brand

T77S1D10-05

TE Connectivity / P&B Brand

Power Relay 5VDC 10A SPST-NO (( 18.2mm 10.2mm 14.7mm)) Through Hole ...

Datasheet
RoHS Compliant
0 Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part T77S1D10-05 is a high-quality power relay designed for various electrical applications. It operates at 5VDC and can handle up to 10A of current. This relay is a Single Pole Single Throw Normally Open (SPST-NO) type, ensuring reliable performance and control over electrical circuits. With compact dimensions of 18.2mm by 10.2mm by 14.7mm, it can be easily mounted on PCBs or through holes. Trust this TE Connectivity / P&B relay for efficient power management in your electronic projects.

Product Highlights:

  • Relay Type = Miniature PCB Relay
  • Relay Style = PCB
  • T77 Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 10 Amps.

Search Keywords: T77S1D1005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T77S1D10-05
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
0
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPST-NO
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-30 to 85 °C
Coil Resistance:
55.6 Ohm

IN STOCK: 2,780

Can Ship immediately

Minimum Order: 100

Multiple: 100

Factory Lead-Time 15 Weeks

Price (CAD)

Qty
Unit Price
100
$2.509
300
$2.417
500
$2.402
1,000 +
$2.387
Suppliers Standard Package
Log in for special pricing
Click for Quote
