T81N5D312-24 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

T81N5D312-24

The T81N5D312-24 is a signal PCB relay featuring a 1 Form C contact arrangement and a 24VDC standard coil. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Discontinued & Replaced
Certificate of Compliance

DESCRIPTION

The T81N5D312-24 is a T81 series signal PCB relay designed for through-hole mounting. It operates with a 24VDC standard coil that consumes 450mW and has a coil resistance of 1280 Ω. The relay features a 1 Form C (CO) contact configuration with gold overlay silver palladium alloy contacts, rated for 1A at 120VAC or 24VDC. With high dielectric strength and a wash-tight case, this component is well-suited for a variety of applications including audio communications circuits, logic and process control, and office automation.

Product Highlights:

  • T81N Series
  • DC Actuating System
  • Input Voltage = 24 VDC
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O
  • Contact Current Rating = 1 Amps.

Search Keywords: T81N5D31224

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T81N5D312-24
Alias/AKA:
7-1393779-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
25
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPDT
Maximum Current Rating:
1 A
Mounting:
Through Hole
Operating Temperature:
-30 to 60 °C
Dimension:
15.4 x 10.9 x 11.7 mm
Termination Style:
PC Pin
Coil Current:
18.75 mA
Contact Form:
1 Form C
Life Cycle:
Discontinued & Replaced
  This product is not in stock and cannot be back-ordered
