Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

T85N11D114-05

The T85N11D114-05 is a miniature, DPDT printed circuit board relay featuring a high-sensitivity coil and a sealed, immersion-cleanable case. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

The T85N11D114-05 is a miniature printed circuit board relay from the T85 series. It operates with a 5V DC coil input, has a coil resistance of 167 Ohms, and consumes a nominal power of 150 mW. The relay provides a DPDT contact arrangement with bifurcated contacts, rated for 1.25A. Key features include a high-sensitivity coil, a DIP terminal arrangement, and a sealed case suitable for immersion cleaning. This component meets FCC Part 68 insolation standards and is designed for mounting on PC boards or in 16-pin IC sockets.

Search Keywords: T85N11D11405

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T85N11D114-05
Alias/AKA:
1393794-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490050
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Dimension:
20.2 x 12.5 x 9.8 mm
Termination Style:
PC Pin
Coil Current:
29.76 mA
Contact Form:
2 Form C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 6,137

Ships today, if you order in

Price (USD)

Qty
Unit Price
1
$16.16
25
$13.50
50
$13.16
100
$12.32
250
$11.20
500 +
$9.84
