T9AP1D52-12 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

T9AP1D52-12

Power Relay 12VDC 30A SPST-NO(50.29mm 27.43mm 27.94mm) Flange ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

TE Connectivity / P&B Brand part T9AP1D52-12 is a high-quality power relay designed for demanding applications. It operates at 12VDC and can handle currents of up to 30A. This relay features a single-pole, single-throw normally open configuration, making it ideal for switching high-powered loads. With its compact dimensions of 50.29mm x 27.43mm x 27.94mm and a flange for easy installation, this power relay is perfect for various industrial and automotive applications. Its robust construction ensures reliable performance and long lifespan, making it a trusted choice for engineers and technicians alike.

Product Highlights:

  • T9A Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 30 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: T9AP1D5212

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T9AP1D52-12
Alias/AKA:
6-1419102-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
OTHER
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Mounting:
Flange Mount
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 85 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 11,972

Ships today, if you order in

On Order: 12,000   can ship 10/12/26

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
5
$7.69
25
$4.70
50
$4.69
100
$4.65
250
$4.60
500
$4.59
1,000
$4.58
2,500 +
$4.56
Supplier's Standard Package
