T9AP1D52-48

Power Relay 48VDC 30A SPST-NO(50.29x27.43x27.94)mm Flange ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

TE Connectivity / P&B Brand part T9AP1D52-48 is a high-quality power relay designed to efficiently control electrical circuits. With a coil voltage rating of 48VDC and a switching current capacity of 30A, this single pole, single throw normally open (SPST-NO) relay is capable of handling heavy-duty applications.The relay features a compact size, measuring 50.29x27.43x27.94mm, which allows for easy installation in space-constrained environments. Its flange design ensures a secure and stable mounting.Built with TE Connectivity / P&B Brand's commitment to reliability and durability, this power relay provides excellent performance and long-lasting operation. It is a versatile component suited for various automotive, industrial, and other electrical applications.Trust TE Connectivity / P&B Brand part T9AP1D52-48 for your power relay needs, delivering efficiency, precision, and dependability in controlling electrical circuits.

Product Highlights:

  • T9A Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 30 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: T9AP1D5248

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T9AP1D52-48
Alias/AKA:
5-1419102-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Package Type:
OTHER
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
48 V
Contact Arrangement:
SPST-NO
Mounting:
Flange Mount
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 85 °C

IN STOCK: 2,936

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks
