T9AS5D22-5

TE Connectivity / P&B Brand

The T9AS5D22-5 is a 1 Form C general-purpose power relay with a 5VDC coil, AgCdO contacts, and combined PCB/Quick Connect terminals. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The T9AS5D22-5 is a T9A series general-purpose power relay designed for high-current switching. It features a 1 Form C (CO) contact arrangement with silver cadmium oxide (AgCdO) contacts, rated for 20A/10A at 240VAC. The relay is operated by a 5VDC coil with a nominal power consumption of 1W and a resistance of 25 Ohms. This model is housed in a wash-tight plastic case and offers flexible mounting with both PCB through-hole pins and 0.250" Quick Connect (QC) terminals. With a maximum operate and release time of 15ms each, it is suitable for applications like HVAC, appliances, and industrial controls.

Product Highlights:

  • T9A Series
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O
  • Contact Current Rating = 30 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: T9AS5D225

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T9AS5D22-5
Alias/AKA:
3-1419104-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
Quick Connect/PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 85 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 21

Ships today, if you order in

On Order: 1,000   can ship 6/1/26

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks
