V23050-A1024-A542 by te connectivity / p-b brand

V23050-A1024-A542

TE Connectivity / P&B Brand

Power Relay 24VDC 8A 4PST-NO/DPST-NC(55mm 16.5mm 16.5mm) THT ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The V23050A1024A542 is a Force Guided Relay with DC coil. This SR6-series relay has 4-form-A and 2-form-B, (4PST-NO, DPST-NC) AgSnO2 contacts. Typical applications such as emergency shut-off, press control, machine control, elevator/escalator control and safety relays.

Product Highlights:

  • Safety Relay SR6
  • V23050 Series
  • DC Actuating System
  • Contact Arrangement = 4 Form A & 2 Form B, 4PST-NO & DPST-NC, 4 N/O & 2 N/C
  • Contact Current Rating = 8 Amps.

Search Keywords: V23050A1024A542

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23050-A1024-A542
RoHS:
Yes
HTS:
8536410050
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
4PST-NO,DPST-NC
Maximum Current Rating:
8 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-25 to 70 °C

IN STOCK: 480

Ships today, if you order in

Minimum Order: 10

Multiple: 10

Factory Lead-Time 34 Weeks

Price (CAD)

Qty
Unit Price
10
$26.460
30
$25.757
50
$25.558
100
$25.434
250
$25.313
500
$25.174
1,000 +
$25.052
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
