V23074A1001A403 by te connectivity / p-b brand

V23074A1001A403

TE Connectivity / P&B Brand

Power Relay 12VDC SPDT(23x15.5x25.4)mm Plug-In ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 8-1393292-4, also known as V23074A1001A403-SZ-CBOX, is a high-performance relay designed for a wide range of automotive and industrial applications. Renowned for its reliability and durability, this relay is capable of handling demanding electrical loads with precision and efficiency. Its robust construction ensures secure operation even in harsh environmental conditions, making it ideal for use in automotive systems, control panels, and other equipment where dependable switching is critical. The compact design of this relay facilitates easy integration into various circuit configurations while maintaining exceptional electrical performance. Whether for OEM applications or for enhancing existing systems, this TE Connectivity relay offers superior quality and long-lasting functionality.

Product Highlights:

  • Nominal Voltage = 12 VDC
  • Rated Current @ 85° C = 15/25 Amps.
  • Product Category = Plug-In Relays
  • Without Mounting Bracket(s)
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O

Search Keywords: V23074A1001A403

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23074A1001A403
RoHS:
Yes
HTS:
8536410020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
480
Package Type:
Box
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT
Maximum Current Rating:
120(NO)/40(NC) A
Mounting:
Connector
Operating Temperature:
-40 to 125 °C
Dimension:
23 x 15.5 x 36.6 mm
Termination Style:
Quick Connect
  Different packaging options available.  See Alternatives

IN STOCK: 0

Minimum Order: 10

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
10
$5.666
50
$4.762
480
$4.212
960
$4.042
1,440
$3.935
2,880
$3.828
5,280
$3.644
7,680 +
$3.400
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
