V23079A1005B301 by te connectivity / p-b brand
Image is representational - see mfr. specs

V23079A1005B301

TE Connectivity / P&B Brand

Signal Relay - 2 form C - Monostable - Contacts: AgNi +Au, 2A 250VAC - Coil: 24VDC, 4114 ohm - PCB Thru Hole ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part V23079A1005B301 is a high-quality signal relay with a compact design. It is designed to operate at 24VDC and can handle a current of up to 2A. This relay features a double-pole, double-throw (DPDT) configuration, making it suitable for various applications in automotive and medical industries.With dimensions of 14.5x7.2x9.8 mm, this through-hole (THT) relay is perfectly suited for space-constrained electronic designs. It is built to meet demanding industry standards and offers reliable performance in harsh environments.Whether you require a relay for automotive control systems or medical equipment, the V23079A1005B301 from TE Connectivity / P&B Brand provides superior functionality and durability. Trust this signal relay to ensure optimal signal transmission and switching capabilities in your critical applications.

Product Highlights:

  • V23079 / P2 Relay Series
  • DC Actuating System
  • Input Voltage = 24 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 2 Amps.

Search Keywords: V23079A1005B301

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23079A1005B301
Alias/AKA:
1-1393788-6
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Dimension:
14.5 x 9.8 x 7.2 mm
Termination Style:
PC Pin
Coil Current:
5.83 mA
Contact Form:
2 Form C

IN STOCK: 16,650

Ships today, if you order in

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 50 Weeks

Price (USD)

Qty
Unit Price
50
$1.96
100
$1.95
250
$1.87
500 +
$1.85
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
