V23079D1005B301 by te connectivity / p-b brand

V23079D1005B301

TE Connectivity / P&B Brand

Signal Relay 24VDC 2A DPDT(14.5x9.4x10.4)mm SMD Automotive Medical ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / P&B Brand part V23079D1005B301 is a high-quality signal relay designed for use in various applications such as automotive and medical industries. This relay operates on a 24VDC voltage with a maximum current rating of 2A. It features a DPDT (Double Pole Double Throw) configuration, providing reliable switching between two separate circuits. With its compact dimensions of 14.5x9.4x10.4mm and surface-mount design, this relay offers easy installation and efficient space utilization. Whether used in vehicle control systems or medical devices, this TE Connectivity / P&B relay delivers exceptional performance and durability.

Product Highlights:

  • V23079 / P2 Relay Series
  • DC Actuating System
  • Input Voltage = 24 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 2 Amps.

Search Keywords: V23079D1005B301

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23079D1005B301
RoHS:
Yes
HTS:
8536490080
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
400
Package Type:
Reel
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
14.5 x 10.4 x 9.4 mm
Termination Style:
Gull Wing
Coil Current:
5.83 mA
Contact Form:
2 Form C

IN STOCK: 696

Can Ship immediately

On Order: 47,296   can ship 2/4/26

Minimum Order: 400

Multiple: 400

Factory Lead-Time 39 Weeks

Price (CAD)

Qty
Unit Price
1
$1.739
400
$1.582
800
$1.574
1,200
$1.565
2,800
$1.558
5,200
$1.549
7,600
$1.542
10,000
$1.534
15,200 +
$1.527
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
