V23079G2003B301 by te connectivity / p-b brand
Image is representational - see mfr. specs

V23079G2003B301

TE Connectivity / P&B Brand

Signal Relay - 2 form C - Monostable - Contacts: AgNi +Au, 2A 250VAC - Coil: 12VDC, 1029 ohm - SMT ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part V23079G2003B301 is a compact and reliable signal relay designed for various applications in automotive and medical industries. With a voltage rating of 12VDC and a contact rating of 2A, this double-pole, double-throw relay combines excellent performance and versatility. Its SMD package measures 14.6mm x 7.2mm x 9.9mm, making it suitable for space-constrained designs. Whether used in automotive control systems or medical equipment, this signal relay offers dependable switching capabilities and ensures optimal performance.

Product Highlights:

  • V23079 / P2 Relay Series
  • DC Actuating System
  • Input Voltage = 12 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 2 Amps.

Search Keywords: V23079G2003B301

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23079G2003B301
Alias/AKA:
5-1393789-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CZ
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
500
Package Type:
Reel
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
14.6 x 9.9 x 7.4 mm
Termination Style:
Gull Wing
Coil Current:
11.66 mA
Contact Form:
2 Form C

IN STOCK: 535

Ships today, if you order in

On Order: 5,000   can ship 4/7/27
On Order: 7,500   can ship 4/21/27

Minimum Order Quantity: 250

Factory Lead-Time 57 Weeks

Price (USD)

Qty
Unit Price
250
$1.70
500
$1.65
1,000
$1.60
2,500
$1.58
5,000 +
$1.56
Reel Package
