V23105A5003A201 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

V23105A5003A201

Signal Relay - 2 form C - Contacts: AgNi+Au, 3A - Coil: 12VDC, 150mW - Thru Hole ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Discontinued & Replaced
Certificate of Compliance

DESCRIPTION

TE Connectivity/P&B Brand part V23105A5003A201 is a compact and efficient signal relay that operates on a 12VDC power supply. This relay provides a double-pole double-throw (DPDT) configuration, making it suitable for various applications that require switching between two different circuits. With its compact dimensions of 20.2x10x11mm, this through-hole technology (THT) relay is designed to be easily integrated into existing circuit boards or enclosures. With a current rating of 3A, this relay offers reliable and high-performance signal transmission. Whether in telecommunications, industrial control, or other electronic systems, this TE Connectivity/P&B relay is a versatile and trustworthy choice.

Product Highlights:

  • V23105 / D2n Relay Series
  • DC Actuating System
  • Input Voltage = 12 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 3 Amps.

Search Keywords: V23105A5003A201

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23105A5003A201
Alias/AKA:
8-1393792-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CZ
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
25
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
3 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Termination Style:
PC Pin
Coil Current:
12.4 mA
Contact Form:
2 Form C
Life Cycle:
Discontinued & Replaced
  This product is not in stock and cannot be back-ordered
