V23105A5505A201 by te connectivity / p-b brand

V23105A5505A201

TE Connectivity / P&B Brand

Signal Relay 24VDC 3A DPDT( (20.2mm 10mm 11mm)) THT ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / P&B Brand part V23105A5505A201 is a high-quality signal relay that is designed to handle 24VDC and deliver a maximum current of 3A. This DPDT (double-pole double-throw) relay is ideal for a range of applications that require switching signals or controlling circuits. With its compact dimensions of 20.2mm length, 10mm width, and 11mm height, this relay can easily fit into tight spaces on printed circuit boards. The Through-Hole Technology (THT) allows for easy installation and secure soldering connections. This signal relay offers excellent performance, reliability, and durability, making it a perfect choice for electronic projects and industrial applications.

Product Highlights:

  • V23105 / D2n Relay Series
  • DC Actuating System
  • Input Voltage = 24 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 3 Amps.

Search Keywords: V23105A5505A201

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23105A5505A201
RoHS:
Yes
HTS:
8536410050
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
3 A
Mounting:
Through Hole
Termination Style:
PC Pin
Operating Temperature:
-40 to 85 °C
Coil Resistance:
1.05 KOhm
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 9,379

Ships today, if you order in

Minimum Order: 25

Multiple: 25

Price (CAD)

Qty
Unit Price
25
$3.874
150
$3.797
250
$3.721
500
$3.660
2,000
$3.583
5,000
$3.124
10,000 +
$2.695
Suppliers Standard Package
Log in for special pricing
Click for Quote
Older Equivalent
2-1393793-1
2-1393793-1
