V23134A0052C643 by te connectivity / p-b brand

V23134A0052C643

TE Connectivity / P&B Brand

Power Relay 12VDC 120(NO)/45(NC)A SPDT(25.9x29.9x51.9)mm Plug-In Automotive ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part V23134A0052C643 is a high-quality power relay that is specifically designed for automotive applications. It is capable of handling up to 120A of current in the Normally Open (NO) position and 45A in the Normally Closed (NC) position, making it ideal for heavy-duty power control in automotive systems. This relay operates at 12VDC and features a Single Pole Double Throw (SPDT) configuration for versatile switching capabilities. Its compact dimensions of 25.9x29.9x51.9mm allow for easy plug-in installation in automotive circuits. With TE Connectivity's renowned reliability and P&B Brand's reputation for excellence, this power relay delivers exceptional performance and durability. It is an essential component for automotive electrical systems, offering reliable power control and protection.

Search Keywords: V23134A0052C643

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23134A0052C643
RoHS:
Yes
HTS:
8536410050
COO:
PT
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
315
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT
Mounting:
Connector
Operating Temperature:
-40 to 125 °C
Termination Style:
Quick Connect

IN STOCK: 619

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 22 Weeks

Price (CAD)

Qty
Unit Price
5
$14.669
25
$12.557
50
$12.282
100
$11.913
315
$11.852
630
$11.791
1,260 +
$11.730
