FN9222-6-07 by te connectivity / schaffner emc
Image is representational - see mfr. specs

FN9222-6-07

TE Connectivity / SCHAFFNER EMC

The FN9222-6-07 is a standard 6A, 250VAC general-purpose IEC inlet filter featuring wire lead connections for power entry applications. ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The FN9222-6-07 is a general-purpose IEC inlet filter that combines a power entry module with a mains filter in a compact, flange-mounted housing. It is rated for a current of 6A at 50°C and a maximum continuous operating voltage of 250VAC. This standard version provides excellent filter attenuation with an inductance of 0.78 mH, a Cx capacitance of 0.1 µF, and Cy capacitance of 2.2 nF. It features wire lead outputs for assembly flexibility and has a typical leakage current of 373 µA. The filter is designed for a wide operating temperature range of -25°C to +85°C, making it suitable for portable electronics, single-phase power supplies, and test and measurement equipment.

Search Keywords: FN9222607

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN9222-6-07
Alias/AKA:
801891-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
120
Package Type:
Box
Type:
Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Flange Mount
Termination Method:
N/A
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
6 A
Operating Frequency:
0 to 400 Hz
Operating Temperature:
-25 to 85 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 117

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
5
$9.79
25
$7.89
50
$7.44
120
$7.08
360
$6.68
600
$6.45
1,080
$6.18
2,520 +
$6.15
Suppliers Standard Package
