FN9222S1R-6-06 by te connectivity / schaffner emc
Image is representational - see manufacturer specifications
TE Connectivity / SCHAFFNER EMC Authorized Distributor

FN9222S1R-6-06

The FN9222S1R-6-06 is a snap-in IEC inlet filter with an integrated bleed resistor, rated for 6A at 250VAC. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The FN9222S1R-6-06 is a general performance IEC inlet filter that combines an IEC inlet and a mains filter in a compact, horizontal snap-in housing. It is designed to operate with a rated current of 6A at 50°C and a maximum continuous voltage of 250VAC. This version includes a 1000 kΩ bleed resistor, an inductance of 0.78 mH, and has a leakage current of 373 µA. With its Faston 6.3 x 0.8mm output terminals and wide operating temperature range of -25°C to +85°C, it provides a practical solution for passing EMI system approvals in applications like portable electronics, single-phase power supplies, and test and measurement equipment.

Search Keywords: FN9222S1R606

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN9222S1R-6-06
Alias/AKA:
803773-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
120
Package Type:
BOX
Type:
Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Snap-In
Termination Method:
Spade/Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
6 A
Operating Frequency:
0 to 400 Hz
Operating Temperature:
-25 to 85 °C

IN STOCK: 240

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$13.72
25
$8.22
120
$6.71
360
$6.23
600
$6.02
1,080
$5.77
2,520
$5.76
5,040 +
$5.74
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
