FN9244-6-06 by te connectivity / schaffner emc
Image is representational - see manufacturer specifications
TE Connectivity / SCHAFFNER EMC Authorized Distributor

FN9244-6-06

The FN9244-6-06 is a high-performance EMC/EMI filter integrated into a standard IEC inlet for superior attenuation in a compact form factor. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The FN9244-6-06 is an IEC inlet filter designed to provide excellent EMC/EMI filtering performance. It operates with a maximum continuous voltage of 250 VAC and is rated for a current of 6 A at 50°C. Key electrical characteristics include an inductance of 4.1 mH, a Cx capacitance of 0.1 µF, and a typical leakage current of 373 µA. This filter is a practical solution for achieving EMI system approval and is well-suited for applications such as portable electronic equipment, single-phase power supplies, and test and measurement equipment.

Search Keywords: FN9244606

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN9244-6-06
Alias/AKA:
804061-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
120
Package Type:
BOX
Type:
Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Flange Mount
Termination Method:
Solder Lug/Faston
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
6 A
Operating Frequency:
0 to 400 Hz
Operating Temperature:
-25 to 85 °C

IN STOCK: 130

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 30

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
5
$8.98
10
$8.96
30
$8.94
60
$6.71
90
$6.26
120 +
$6.13
Supplier's Standard Package
Log in for special pricing
