FN9264S-6-06 by te connectivity / schaffner emc
Image is representational - see manufacturer specifications
TE Connectivity / SCHAFFNER EMC Authorized Distributor

FN9264S-6-06

The FN9264S-6-06 is a compact, snap-in IEC inlet filter module with an integrated 2-pole rocker switch, rated for 6A at 250VAC. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The FN9264S-6-06 is a filtered power entry module that combines an IEC inlet, mains filter, and a 2-pole rocker switch in a compact, snap-in housing. It is designed for a rated current of 6A at 40°C and a maximum continuous operating voltage of 250 VAC. Key filter components include a 0.3 mH inductor, a 0.1 µF X-capacitor, and two 2.2 nF Y-capacitors, providing good attenuation performance. The module's snap-in design and Faston 6.3 x 0.8mm terminals facilitate easy assembly, making it ideal for portable electronic equipment, office equipment, and single-phase power supplies.

Search Keywords: FN9264S606

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN9264S-6-06
Alias/AKA:
811703-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
60
Package Type:
BOX
Type:
Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Flange Mount
Termination Method:
Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
6 A
Operating Frequency:
50 to 400 Hz
Operating Temperature:
-25 to 85 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 60

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 15

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$24.65
10
$20.95
15
$20.11
30
$19.31
45
$19.27
60 +
$16.81
Supplier's Standard Package
