CCR-33S10 by teledyne coax

CCR-33S10

Teledyne Coax

RF Coaxial Switch - 18GHz - 50 Ohms - SPDT - Failsafe - DC 28V Coil Voltage - 90 mA - Female SMA - 60 dB Isolation - 3 Positions - 47 g - 38.1 x 13.21 x 39.88 mm - Screw Mount

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TELEDYNE COAX CCR-33S10 is a RF , SPDT, electromechanical Coaxial Switch, designed to switch a microwave signal from a common input to either of two outputs. The switches are small with connector spacing compatible with SMA connectors.

Search Keywords: CCR33S10

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Coax
Part No:
CCR-33S10
RoHS:
Yes
HTS:
8542390001
COO:
TW
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Impedance (Ohms):
50
Switch Configuration:
1P2T (SPDT)
Connector:
SMA Female
Actuator Feature:
Failsafe
Typical Operating Supply Voltage:
28 VDC
Actuation Current (mA - Typ):
90
Maximum Frequency:
18 GHz
Insertion Loss - Max Frequency (dB):
0.4 (Typ)
Isolation - Max Frequency (dB):
65 (Typ)
Insertion Loss - Min Frequency (dB):
0.1 (Typ)
Isolation - Min Frequency (dB):
90 (Typ)
Indicator Contacts:
N
Self-Cutoff:
Not App
Coil Transient Suppression Diodes:
N
TTL Drivers:
N
Decoders:
Not App
D-Sub Connector:
N
Moisture Seal:
N
Narrow Body:
N
Positve Common:
Not App
Operating Temperature:
-40 to 65 °C

IN STOCK: 142

Can Ship immediately

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$218.010
3
$214.807
5
$213.735
10 +
$197.750
