CCR-33S1C by teledyne coax

CCR-33S1C

Teledyne Coax

RF Switch Commercial - 50 Ohms - 28VDC Coil - DC-18GHz - Failsafe - SPDT - SMA-Female - Opt: Indicator-Contacts ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TELEDYNE COAX CCR-33S1C is a high-performance RF switch designed for commercial applications. With a 50 Ohms impedance and a 28VDC coil voltage, this switch operates in a wide frequency range from DC to 18GHz. Featuring a failsafe design, the CCR-33S1C ensures reliable and secure switching of RF signals. It utilizes a single-pole, double-throw (SPDT) configuration with SMA-Female connectors, offering excellent connectivity and compatibility with various RF devices.Additionally, this RF switch offers the option for an indicator and contacts, providing enhanced control and monitoring capabilities. Whether used in telecommunications, aerospace, or other RF applications, the TELEDYNE COAX CCR-33S1C delivers exceptional performance, reliability, and versatility.

Search Keywords: CCR33S1C

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Coax
Part No:
CCR-33S1C
RoHS:
No
HTS:
8542390000
COO:
TW
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Impedance (Ohms):
50
Switch Configuration:
1P2T (SPDT)
Connector:
SMA Female
Actuator Feature:
Failsafe
Typical Operating Supply Voltage:
28 VDC
Actuation Current (mA - Typ):
90
Maximum Frequency:
18 GHz
Insertion Loss - Max Frequency (dB):
0.4 (Typ)
Isolation - Max Frequency (dB):
65 (Typ)
Insertion Loss - Min Frequency (dB):
0.1 (Typ)
Isolation - Min Frequency (dB):
90 (Typ)
Indicator Contacts:
Y
Self-Cutoff:
Not App
Coil Transient Suppression Diodes:
N
TTL Drivers:
N
Decoders:
Not App
D-Sub Connector:
N
Moisture Seal:
N
Narrow Body:
N
Positve Common:
Not App
Operating Temperature:
-40 to 65 °C

IN STOCK: 0

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$210.954
3
$207.844
5
$202.230
10 +
$195.329
Log in for special pricing
Click for Quote
