CCR-33S20 by teledyne coax

CCR-33S20

Teledyne Coax

Coaxial Switch - SPDT - 3 Position - 15 VDC Failsafe - 18 GHz - 50 Ohms - 1.5:1 VSWR - Non-Illuminated - SMA Female Connector. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TELEDYNE COAX part CCR-33S20 is a reliable and versatile RF switch designed for commercial applications. With its 50 Ohm impedance and failsafe operation, this switch ensures efficient signal transmission and minimizes interference. Featuring a single-pole, double-throw (SPDT) configuration, this switch can effectively alternate between two different RF signals. The SMA-female connectors provide a secure and easy-to-use interface. With a wide frequency range of DC-18GHz, this switch is capable of handling diverse RF systems. Powered by a 15VDC coil, it offers excellent performance and stability. The TELEDYNE COAX CCR-33S20 is an ideal choice for demanding RF applications in various industries.

Search Keywords: CCR33S20

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Coax
Part No:
CCR-33S20
RoHS:
Yes
COO:
TW
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Impedance (Ohms):
50
Switch Configuration:
1P2T (SPDT)
Connector:
SMA Female
Actuator Feature:
Failsafe
Typical Operating Supply Voltage:
15 VDC
Actuation Current (mA - Typ):
250
Maximum Frequency:
18 GHz
Insertion Loss - Max Frequency (dB):
0.4 (Typ)
Isolation - Max Frequency (dB):
65 (Typ)
Insertion Loss - Min Frequency (dB):
0.1 (Typ)
Isolation - Min Frequency (dB):
90 (Typ)
Indicator Contacts:
N
Self-Cutoff:
Not App
Coil Transient Suppression Diodes:
N
TTL Drivers:
N
Decoders:
Not App
D-Sub Connector:
N
Moisture Seal:
N
Narrow Body:
N
Positve Common:
Not App
Operating Temperature:
-40 to 65 °C

IN STOCK: 27

Can Ship immediately

MOQ for out of Stock Qty: 2

Factory Lead-Time 12 Weeks
