ER412DM4-26A by teledyne relays
Image is representational - see manufacturer specifications
Teledyne Relays Authorized Distributor

ER412DM4-26A

The ER412DM4-26A is an established reliability, DPDT non-latching TO-5 relay with an internal transient suppression diode and a nominal coil voltage of 26.5V. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The ER412DM4-26A is a high-reliability, non-latching DPDT relay in a hermetically sealed TO-5 package, featuring an internal diode for coil transient suppression. It operates on a nominal coil voltage of 26.5 Vdc with a maximum pickup voltage of 18.0 Vdc and has a coil resistance of 1560 ohms. The relay's 2 Form C (DPDT) contacts are rated for DC resistive loads up to 1 A at 28 Vdc and it is designed for continuous duty across a wide operating temperature range of –65°C to +125°C. With its all-welded construction, high resistance to shock (75 g's) and vibration (30 g's), this relay ensures reliable performance in harsh environments. Its ultraminiature size makes it ideal for high-density PC board applications, including low-level and RF switching.

Search Keywords: ER412DM426A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Relays
Part No:
ER412DM4-26A
Alias/AKA:
ER412DM4-26A/G
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536410020
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Type:
Established Reliability Relay
Relay Construction:
Non-Latching
Contact Arrangement:
DPDT
AC Coil Voltage:
N/A
DC Coil Voltage:
26.5 V
Maximum Current Rating:
1DC,0.25AC A
Coil Current:
16.99 mA
Coil Resistance:
1.56 KOhm
Mounting:
Through Hole
Operating Temperature:
-65 to 125 °C
Termination Style:
PC Pin
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 38

Can Ship immediately

MOQ for out of Stock Qty: 13

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
1
$167.93
5
$155.15
10
$132.14
13
$131.81
25
$127.63
38
$127.31
50 +
$113.60
